CUSHY FOOT / ISO Mounts provide large deflection, high load capacity and long service life. These Mounts are made in such a manner that the rubber is protected from OIL and physical damages by robust casting.

The main Different types of Machine vibration isolated with Cushy foot mounting include :
Centrifuges, Generators, Compressors , Crushers, Diesel engines, Engine test beds, Pipe Supports(Exhaust systems), Food processing machinery, Hammer mills, Hydraulic Machinery, Mining Machinery, Metal Forming Presses, Pumps, rotary dryers and sifters etc.

SERIES A

Mounting Reference No. Max.Load Capacity(Kg) Deflection (mm) Top Fixing Hole Dimension
Plain – Tapped
A4 77 5.6 10 – M16
A3 118 5.8 10 – M16
A2 153 6.1 10 – M16
A1 235 5.8 10 – M16
AC 317 5.3 10 – M16

SERIES B

Mounting Reference No. Max.Load Capacity(Kg) Deflection (mm) Top Fixing Hole Dimension
Plain – Tapped
B4 272 6.3 13 – M16
B3 544 5.6 13 – M16
B2 850 5.6 13 – M16
B1 1040 5.6 13 – M16
BC 1580 5.6 13 – M16

SERIES HD

Mounting Reference No. Max.Load Capacity(Kg) Deflection (mm) Top Fixing Hole Dimension
Plain – Tapped
HD3 631 14.00 13 – M16
HD2 833 14.00 13 – M16
HD1 1280 14.00 13 – M16

Dimensions

The Dimensions of Cushyfoot A and B Series mountings are shown below. The dimensions of the High Defiection (HD) mounting are the same as those of B series except thst the free(unladen) height of the HD is 119 mm due to the different bonded rubber elements employed

Also, Bottom Friction pads can be provided to avoid conventional foundation on Floor.
