RECTANGULAR PLATE SHEAR MOUNTS
RECTANGULAR PLATE SHEAR MOUNTS ( RECAE/1 ) - Image 2
RECTANGULAR PLATE SHEAR MOUNTS ( RECAE/1 ) - Image 3
RECTANGULAR PLATE SHEAR MOUNTS ( RECAE/1 ) - Image 4

RECTANGULAR PLATE SHEAR MOUNTS ( RECAE/1 )

$75.76

PRODUCT FEATURES:
Material : Natural Rubber, Metal-Zinc plated

Load Specifications ( FOR SERIES-2)

Comp. Max Load Comp. Max Deflection Shear Max Load Shear Max Deflection Brand
360 Kg 4 mm 40 kg 8.5 mm AE Mounts

AVAILABLE IN FOLLOWING SERIES :

SERIES-1  = 40 +/- 5 SHORE -A NATURAL RUBBER

SERIES-2  = 50 +/- 5 SHORE -A NATURAL RUBBER

SERIES-3  = 60 +/- 5 SHORE -A NATURAL RUBBER

SERIES-4  = 70 +/- 5 SHORE -A NATURAL RUBBER

SKU: RECAE/1 Category:

Description

RECTANGULAR PLATE SHEAR ISOLATORS/MOUNTS

Available in 4 different hardness ( 40 Shore A to 70 Shore A ) to suit various load requirements.

Specification:

Material: Natural Rubber, Metal-Zinc plated and Black Painted Standard

Package : 1 mount per pack.

Application:

  • Standard products are made from high grade Natural rubber (50-55 Shore A)
  • All metal plates that we use are treated with anti-rust coatings.
  • The Anti-Vibration Damper can reduce the vibration of the machine and enhance the life of the machinery.

We have a stock of wide range of Anti-Vibrations Mounts and if the product you are after is not in stocked items than you can send us your inquiry on akszn@outlook.com
We pride ourselves on our quality and customer service so we endeavor to get back to you within 24 hrs. We offer good discounts based on higher quantities.

Additional information

Rubber Hardness

Shore-40, Shore-50, Shore-60, Shore-70
